GRAND COURT
ORGAN STOP SPECIFICATIONS
CHOIR ORGAN
Manual I – Enclosed
PITCH STOP
NAME WOOD/METAL PIPES
16 DOUBLE DULCIANA M 61
8 OPEN DIAPASON M 61
8 VIOLIN DIAPASON M 61
8 STOPPED DIAPASON W 61
8 CONCERT FLUTE W 61
8 QUINTADENA M 61
8 SALICIONAL M 61
8 VOX
CELESTE M 49
8 VOX
ANGELICA M 61
8 KERAULOPHONE M 61
8 DULCIANA M 61
4 SALICET M 61
4 FORREST
FLUTE W 61
2 PICCOLO M 61
VI SOFT
CORNET M 366
12/15/17/19/22/26
16 SAXOPHONE M 61
8 SAXOPHONE M 61
8 ENGLISH HORN M 61
8 CLARINET M 61
CHOIR
TREMOLO I
CHOIR
TREMOLO II
GREAT ORGAN
Manual II - Unenclosed Division
PITCH STOP
NAME WOOD/METAL PIPES
32 SUB
PRINCIPAL M 61
16 DOUBLE
DIAPASON M 61
16 CONTRA
GAMBA M 61
10 2/3 SUB QUINT W 61
8 MAJOR DIAPASON W/M 61
8 DIAPASON
PHONON W/M 61
8 DIAPASON I W/M 61
8 DIAPASON II W/M 61
8 DIAPASON III W/M 61
8 DIAPASON IV W 61
8 GAMBA ‑
2 RANKS M 122
8 MAJOR TIBIA W 61
8 MEZZO TIBIA W 61
8 MINOR TIBIA W 61
8 DOUBLE FLUTE W 61
8 NASARD FLUTE ‑
2 RANKS M 122
4 OCTAVE M 61
VIII MIXTURE
- 32' M 476
1/5/8/10/12/15/17/19
8 TRUMPET M 61
GREAT ORGAN
Manual II - Enclosed Division (Enclosed
With Choir)
PITCH STOP
NAME WOOD/METAL PIPES
8 COVERED TIBIA W 61
8 HARMONIC FLUTE M 61
5
1/3 QUINT M 61
4 PRINCIPAL M 61
4 HARMONIC FLUTE M 61
3 1/5 TIERCE M 61
2 2/3 OCTAVE
QUINT M 61
2 SUPER OCTAVE M 61
VII MIXTURE M 427
12/15/17/19/22/26/29
16 DOUBLE TRUMPET M 61
8 TUBA M 61
8 HARMONIC TRUMPET M 61
4 HARMONIC CLARION M 61
GREAT
TREMOLO I
GREAT
TREMOLO II
GREAT
TIBIA TREMOLO
GREAT ORGAN ‑
CHORUS DIVISION
Manual II - Unenclosed
PITCH STOP
NAMES WOOD/METAL PIPES
8 CHORUS DIAPASON MAGNA M 61
8 CHORUS STENTORPHONE W/M 73
8 CHORUS OPEN DIAPASON I W/M 73
8 CHORUS OPEN DIAPASON II W/M 73
8 CHORUS OPEN DIAPASON III W 73
8 CHORUS GAMBA M 73
8 CHORUS MAJOR FLUTE W 73
8 CHORUS DOUBLE FLUTE W 73
4 CHORUS OCTAVE M 73
4 CHORUS FLUTE W 73
2
2/3 CHORUS NASARD M 61
CHORUS
TREMOLO
SWELL ORGAN
Manual III
– Enclosed
PITCH STOP
NAME WOOD/METAL PIPES
16 DOUBLE DIAPASON M 61
16 SOFT BOURDON W 61
8 STENTORPHONE W/M 61*
8 HORN DIAPASON M 61
8 VIOLIN DIAPASON M 61
8 BELLFLUTE M 61
8 TIBIADURA W 61
8 GRAND FLUTE‑2 RANKS W 122
8 DOUBLE FLUTE W 61
8 CLARABELLA W 61
8 ORCHESTRAL FLUTE W 61
8 HARMONIC FLUTE M 61
8 MELODIA W 61
8 GAMBAI M 61
8 GAMBA CELESTE‑2
RANKS M 122
8 SOFT DULCIANA M 61
5-1/3 QUINT BOURDON W 61
4 OCTAVE I M 61
4 OCTAVE II M 61
4 HARMONIC FLUTE‑2 RANKS M 122
2-2/3 NASARD M 61
2 HARMONIC PICCOLO M 61
IV STRING MIXTURE M 305
15/17/19/24/26
VI MIXTURE M 438
12/15/17/19/22/26
16 BASS
TUBA M 61*
16 BASS
TROMBONE M 61*
8 TUBA
SONORA M 61*
8 TROMBONE M 61*
4 HARMONIC CLARION M 61*
16 CONTRA FAGOTTO M 61
16 DOUBLE OBOE HORN M 61
8 TRUMPET M 61
8 HORN M 61
8 FAGOTTO M 61
8 OBOE M 61
8 BASSETHORN M 61
8 CLARINET M 61
8 CLARINET‑2 RANKS M 122
8 VOX HUMANA‑2
RANKS M 122
4 MUSETTE M 80
* 22” pressure
SWELL ORGAN ‑ ORIGINAL
STRING DIVISION
PITCH STOP
NAME WOOD/METAL PIPES
16 CONTRA
BASS W/M 61
8 VIOLIN
CELLO M 61
8 VIOL M 61
8 VIOL ‑ SHARP M 61
8 VIOLA M 61
5-1/3 QUINT
VIOL M 61
4 VIOLINA M 61
4 OCTAVE
VIOL M 61
3-1/5 TIERCE M 61
IV VIOL
CORNET M 244
12/15/17/22
V CORROBORATING MIXTURE M 305
17/19/22/26/29
SWELL
TREMOLO I
SWELL
TREMOLO II
SOLO
ORGAN
Manual IV - Enclosed
PITCH STOP
NAME WOOD/METAL
PIPES
16 DOUBLE
OPEN DIAPASON M 73
16 GRAND
VIOL M 73
8 OPEN
DIAPASON I W/M 73
8 OPEN
DIAPASON II W/M 73
8 OPEN
DIAPASON III W/M 73
8 VIOLIN
DIAPASON M 73
8 CLARABELLA W 73
8 TIERCE
FLUTE ‑ 2 RANKS M 146
8 HARMONIC
FLUTE M 73
8 CHIMNEY FLUTE M 73
8 GRAND GAMBA M 73
8 GRAND GAMBA - SHARP M 73
8 NASARD
GAMBA
- 2 RANKS M 146
8 VIOL M 73
8 VIOL
‑
SHARP M 63
8 GEMSHORN M 73
8 QUINTAPHONE W 73
5 1/3 QUINT DIAPASON M 73
4 OCTAVE M 73
4 HARMONIC
FLUTE M 73
3 1/5 HARMONIC TIERCE M 73
2 2/3 12TH
HARMONIC M 73
2 HARMONIC
PICCOLO M 73
V MIXTURE M 365
8/12/15/17/19
VI MIXTURE M 438
12/15/19/22/24/26
VI GRAND
MIXTURE M 438
5/8/12/15/19/22
16 TUBA M 73
16 DOUBLE
TRUMPET M 73
8 OPHICLEIDE M 73
8 CORNOPEAN M 73
8 SOFT TUBA M 73
8 TRUMPET M 73
8 MUSETTE M 73
4 OPHICLEIDE M 73
4 SOFT TUBA M 73
SOLO TREMOLO I
SOLO TREMOLO II
ETHEREAL ORGAN
Manual V - Enclosed
PITCH STOP
NAME WOOD/METAL PIPES
16 BOURDON W 73
8 OPEN
DIAPASON 1 M 73
8 OPEN
DIAPASON II M 73
8 CLEAR
FLUTE W 73
8 HARMONIC
FLUTE M 73
8 DOUBLE
FLUTE W 73
8 GRAND
GAMBA M 73
8 GRAND
GAMBA
‑
SHARP M 64
5-1/3 QUINT
FLUTE W 73
4 OCTAVO M 73
4 HARMONIC
FLUTE M 73
2-2/3 12TH
HARMONIC M 73
2 HARMONIC
PICCOLO M 73
IV MIXTURE M 292
5/8/12/15
16 TUBA
PROFUNDA M 73
8 TUBA
MIRABILIS M 73
8 FRENCH
TRUMPET M 73
8 GRAND
CLARINET M 73
4 TUBA
CLARION M 73
ETHEREAL TREMOLO I
ETHEREAL TREMOLO II
STENTOR ORGAN
Manual VI
The Stentor Division was intended to be a
large manual and pedal division consisting of high-pressure diapasons and
reeds. It was to be installed on the
fifth floor above the String organ but was never realized. The Stentor keyboard
is in operation and all floating divisions and percussion instruments can be
played from it. In addition, several
important solo voices are now available independantly on the Stentor Manual,
using some of the previously blank Stentor stop tabs.
8’ String
Cello I (natural)
8’
String Cello I (flat)
8’
String Cello I (sharp)
8’
String Cello II (natural)
8’
String Cello II (flat)
8’
String Cello II (sharp)
8’ String Nasard Gamba, 2 rks, (natural)
8’ String Nasard Gamba, 2 rks, (sharp)
8’ Ethereal Clear Flute
4’ Ethereal Clear Flute
8’ Chorus
Magna Diapason
16’ String
Celli to Celli
String Celli
Unison Off
Stentor
Tremolo I
Stentor
Tremolo II
ECHO ORGAN
Floating - Enclosed
PITCH STOP
NAMES WOOD/METAL
PIPES
16 BOURDON W 61
8 OPEN
DIAPASON M 61
8 VIOLIN
DIAPASON M 61
8 STOPPED
DIAPASON W 61
8 NIGHTHORN M 61
8 CLARABELLA W 61
8 MELODIA W 61
8 ORCHESTRAL
VIOL M 61
8 SOFT VIOL M 61
8 SOFT
VIOL (SHARP) M 61
8 UNDA MARIS (2 RANKS) W/M 110
5-1/3 OPEN QUINT M 61
4 OCTAVE M 61
4 HARMONIC
FLUTE M 61
4 MELLOW
FLUTE W 61
VI MIXTURE M 366
5/8/12/15/17/19
V CORNET M 305
12/15/17/19/22
16 DOUBLE
TRUMPET M 61
8 TRUMPET M 61
8 CAPPED
OBOE M 61
8 EUPHONE M 73
8 VOX
HUMANA ‑ 2 RANKS M 122
ECHO
TREMOLO I
ECHO
TREMOLO II
ORCHESTRAL ORGAN
Floating – Enclosed
Unavailable; awaiting restoration
PITCH STOP
NAMES WOOD/METAL PIPES
16 CONTRA
QUINTADENA W/M 73
8 DUOPHONE W 73
8 TIBIA W 73
8 COVERED
TIBIA W 73
8 CONCERT
FLUTE W 73
8 HARMONIC
FLUTE M 73
8 MELLOW
FLUTE W 73
8 STRING
FLUTE W 73
8 DOUBLE
FLUTE W 73
8 HOLLOW
FLUTE W 73
4 OCTAVE M 73
4 HARMONIC
FLUTE M 73
4 ORCHESTRAL
FLUTE W 61
4 COVERED
FLUTE W/M 73
2 HARMONIC
PICCOLO M 61
16 ENGLISH
HORN M 73
16 BASS
CLARINET M 73
16 BASS
SAXOPHONE M 73
16 BASSOON M 73
8 POST
HORN M 73
8 ORCHESTRAL
BASSOON M 73
8 ORCHESTRAL
CLARINET M 73
8 ENGLISH
HORN M 73
8 OBOE M 73
8 ORCHESTRAL
OBOE M 73
8 BASSETT
HORN M 73
8 SAXOPHONE M 73
8 FRENCH
HORN I M 73
8 FRENCH
HORN II M 73
8 FRENCH
HORN III M 73
8 MUTED
CORNET M 73
8 KINURA M 73
16 VOX
HUMANA M 73
8 VOX
HUMANA I M 73
8 VOX
HUMANA II M 73
8 VOX
HUMANA III M 73
8 VOX HUMANA IV M 73
8 VOX HUMANA V M 73
8 VOX
HUMANA VI M 61
ORCHESTRAL
TREMOLO I
ORCHESTRAL
TREMOLO II
STRING ORGAN
Floating - Enclosed
PITCH STOP
NAME
All Pipes are Metal unless otherwise
noted.
All
Ranks have 73 pipes unless otherwise noted.
16 VIOLONE n = NATURAL
16 CONTRA
GAMBA I s = SHARP
16 CONTRA
GAMBA II f = FLAT
16 CONTRA
VIOL I
16 CONTRA
VIOL II
16 VIOL
I
16 VIOL
II
8 VIOLIN
DIAPASON
8 GAMBA
8 CELLO
I n
8 CELLO
I s
8 CELLO
I f
8 CELLO
II n
8 CELLO
II s
8 CELLO
II f
8 NASARD
GAMBA ‑ 2 Ranks n 146
8 NASARD
GAMBA ‑ 2 Ranks s 146
8 ORCHESTRAL
VIOLIN I n
8 ORCHESTRAL
VIOLIN I s
8 ORCHESTRAL
VIOLIN I f
8 ORCHESTRAL
VIOLIN II n
8 ORCHESTRAL
VIOLIN II s
8 ORCHESTRAL
VIOLIN II f
8 ORCHESTRAL
VIOLIN III n
8 ORCHESTRAL
VIOLIN III s
8 ORCHESTRAL
VIOLIN III f
8 ORCHESTRAL
VIOLIN IV n
8 ORCHESTRAL
VIOLIN IV s
8 ORCHESTRAL
VIOLIN IV f
8 ORCHESTRAL
VIOLIN V n
8 ORCHESTRAL VIOLIN V
s
8 ORCHESTRAL VIOLIN V
f
8 ORCHESTRAL VIOLIN VI n
8 ORCHESTRAL
VIOLIN VI s
8 ORCHESTRAL VIOLIN VI f
8 MUTED VIOLIN I n
8 MUTED VIOLIN I s
8 MUTED VIOLIN I f
8 MUTED VIOLIN II n
8 MUTED VIOLIN II s
8 MUTED VIOLIN II f
8 MUTED VIOLIN III
n
8 MUTED VIOLIN III
s
8 MUTED VIOLIN III
f
8 MUTED VIOLIN IV n
8 MUTED VIOLIN IV s
8 MUTED VIOLIN IV f
8 MUTED VIOLIN V n
8 MUTED VIOLIN V s
8 MUTED VIOLIN V f
8 MUTED
VIOLIN VI n
8 MUTED VIOLIN VI s
8 MUTED VIOLIN VI f
5 1/3 QUINT VIOL n
5 1/3 QUINT VIOL s
4 ORCHESTRAL VIOLINA I n
4 ORCHESTRAL
VIOLINA
I s
4 ORCHESTRAL
VIOLINA
II n
4 ORCHESTRAL
VIOLINA
II s
3 1/5 TIERCE VIOL
n 61
3 1/5 TIERCE VIOL
s 61
2 2/3 NASARD
VIOLINA
n
2 2/3 NASARD
VIOLINA
s
2 SUPER
VIOLINA
n
2 SUPER
VIOLINA
s
8 DULCIANA
I n
8 DUCLIANA
I s
8 DULCIANA
II n
8 DULCIANA
II s
8 DULCIANA
III n
8 DULCIANA
III s
8 DULCIANA
IV n
8 DULCIANA
IV s
8 DULCIANA‑V
n
8 DULCIANA
V s
8 DULCIANA
VI n
8 DULCIANA
VI s
4 OCTAVE DULCIANA I n
4 OCTAVE DULCIANA I s
4 OCTAVE DULCIANA II n
4 OCTAVE DULCIANA II s
MUTATION
12TH 61
MUTATION 15TH 61
MUTATION 19TH 61
MUTATION 22ND 61
MUTATION 26TH 61
V DULCIANA
MIXTURE (draws above Mutations)
12/15/19/22/26
STRING
TREMOLO I
STRING
TREMOLO II
MAIN PEDAL ORGAN
PITCH STOP
NAMES WOOD/METAL PIPES
64 GRAVISSIMA
(RESULTANT) W 25 (Sub Quint)
(32 Open Diapason I + Independent 21
1/3 Sub Quint)
32 CONTRA DIAPHONE W 32
32 CONTRA
OPEN DIAPASON I W 32
32 CONTRA OPEN DIAPASON II M From Great
32 CONTRA BOURDON W 32
16 DIAPHONE W 12
16 OPEN DIAPASON I W 32
16 OPEN DIAPASON II M 32
16 OPEN DIAPASON III W 32
16 OPEN FLUTE W 32
16 BOURDON W 32
16 VIOLONE W 32
16 GAMBA M 32
16 SOFT BOURDON W From Swell
16 DULCIANA M From Choir
10 2/3 OPEN
QUINT M 32
10 2/3 STOPPED
QUINT W 32
8 OCTAVE M 32
8 OPEN DIAPASON W 32
8 STENTOR W/M 12
8 TIBIA
I W 32
8 TIBIA
II W 12
8 SOFT
FLUTE W 32
8 SOFT
OCTAVE BOURDON W 32
8 CELLO I M 32
8 CELLO
II M 32
8 SOFT
DULCIANA M 32
4 OCTAVE M 32
4 PRINCIPAL M 32
4 TIBIA
I W 32
4 TIBIA II W 12
4 FLUTE W 32
VIII MIXTURE
32 M From
Great
1/5/8/10/12/15/17/19
VI MIXTURE 16 M From Great
8/10/12/15/17/19
VII MIXTURE M 224
10/12/15/17/19/22/24
XI GRAND
MUTATION M 320
1/5/8/10/12/15/17/19/22/24
32 CONTRA
BOMBARDE W 32
16 BOMBARDE W/M 12
16 TUBA M 32
16 TROMBONE M 32
8 BOMBARDE W/M 12
8 TROMBA M 32
4 CLARION M 32
16 CONTRA
FAGOTTO M 32
8 FAGOTTO M 32
16 EUPHONIUM M 32
ETHEREAL
PEDAL
PITCH STOP
NAMES WOOD/METAL PIPES
32 ACOUSTIC BASS (RESULTANT) W 32 (Open Quint)
(16 Open Diapason +
Independent 10 2/3 Open Quint)
16 OPEN DIAPASON W 32
16 BOMBARDE M 32
8 BOMBARDE M 32
ECHO PEDAL
PITCH STOP
NAMES WOOD/METAL PIPES
16 OPEN
DIAPASON W 32
16 STOPPED DIAPASON W 32
ORCHESTRAL PEDAL
PITCH STOP
NAMES WOOD/METAL PIPES
16 VOX
HUMANA I M 32
16 VOX
HUMANA
II M 32
STRING PEDAL
32 STRING DIV. CONTRA DIAPHONE W 32
32 STRING CONTRA GAMBA M 32
16 STRING DIAPHONE W 12
16 STRING DIV. GAMBA M 12
16 STRING DIV. VIOLONE I W 32
16 STRING DIV. VIOLONE II M 32
16 STRING DIV. VIOL M 32
16 STRING DIV. VIOL ‑
SHARP M 32
8 STRING DIV. DIAPHONE W/M 12
8 STRING DIV. GAMBA M 12
8 STRING
DIV. VIOLONE I W 12
8 STRING DIV. VIOLONE II M 12
8 STRING DIV. VIOL M 12
8 STRING DIV. VIOL ‑
SHARP M 12
4 STRING DIV. VIOLONE M 12
16 STRING MUTATION DIAPHONE M 32
16 STRING MUTATION VIOLONE M 32
10
2/3 STRING MUTATION M 32
8 STRING MUTATION M 32
5-1/3 STRING MUTATION M 32
4 STRING MUTATION M 32
2-2/3 STRING MUTATION M 32
2 STRING MUTATION M 32
1-3/5 STRING MUTATION M 32
1-1/3 STRING MUTATION M 32
4/5 STRING MUTATION M 32
XII GRAND STRING DIV. MIXTURE
(Draws 32 Diaphone +
Above Mutations)
PEDAL
TREMOLO I
PERCUSSION DIVISION
Floating
MAJOR CHIMES 37 TUBULAR CHIMES;
TENOR C TO c1
MINOR
CHIMES 25
TUBULAR CHIMES; TENOR G TO g
METALOPHONE 49
METAL BARS; TENOR C TO c5
CELESTA 49
METAL BARS; TENOR C TO c5
This is an original Mustel Celesta
GONGS 49
BRASS RESONATORS; TENOR C TO c5
PIANO I 88
NOTES, VACUUM ACTION;
This is an upright piano with a
player-like action.
The
console is prepared for a Piano II, a Harp I and a Harp II.
COUPLERS AND
ACCESSORIES
Full
compliment of inter- and intra-manual couplers
Independent,
full compliment of expression couplers
Expression sliders (under
each manual, controlled with the thumb)
Three
settable Tuttis
Crescendo
Pedal with Divisional Cutouts
Full
compliment of divisional pistons
46
General pistons
Ten-stage speed controls for both
tremolos
(The Stentor Expression shoe also
controls the Tremolo I speed control; the Percussion Expression shoe also
controls Tremolo II speed control)
BLOWERS
MAIN BLOWER ROOM (2nd Gallery ‑ behind
Main Organ Chamber)
High Pressure Blower 60 HP 870
RPM 18 ‑ 25 inches H20 ‑
11.500 CFM +/-
Low Pressure Blower 20 HP 1150
RPM 8 inches H20 ‑ 6750 CFM
Chorus Division Blower 20 HP 880
RPM 24 inches H20
Motor
Generator – I 5
HP 1140 RPM, 5 ‑
10 Volt DC-500 ‑ 250 AMP
Motor
Generator ‑ II 2 HP 1720 RPM, 9 Volt
DC ‑140 AMP
SUCTION
BLOWER ROOM
(2nd
Gallery ‑behind Main Organ Chamber)
Suction
Blower 3 HP 1150 RPM 20 inches H20‑
Vacuum
STRING
&
ETHEREAL
BLOWER ROOM (4th Floor ‑behind String
Chamber)
String
Division Blower 30 HP 1750
RPM 20 inches H20 5600 CFM
Ethereal
Division Blower 25 HP 1750
RPM 34 inches H20 2700
CFM
ECHO
ORGAN (7th Floor ‑ in Echo
Chamber)
Echo
Division Blower
3 HP 870 RPM 5
inches H20
MAIN COMPONENTS
The
chests, reservoirs, and pipes are divided as follows:
Division Location Chests Reservoirs Wind Pressure Stops Ranks Pipes
Choir Main
Chamber 5 1 5" 19 24 1452
Great Main Chamber 8 2 5"‑ 11" 32 47 2867
Swell Main
Chamber 12 4 5"
‑
7" ‑ 22˝" 51 71 4410
Solo Main
Chamber 8 4 15" 35 51 3640
Ethereal 7th
Floor South 13 3 20" ‑ 25" 23 26 1652
String 4th
Floor South 32 7 15" ‑ 27" 114 105 6992
Orchestral Main Chamber 13 2 15" ‑ 20" 42 41 2875
Echo 7th Floor North 8 2 5" 24 35 2077
Chorus Main
Chamber 7 3 14"‑16"‑18" 11 11 779
Pedal Main
Chamber 31 2 5"
‑
24" 48 50 1682
Relays Main
Chamber 0 2 6"‑9"
Tremolo Action Main Chamber 0 1 5"
Major Chimes 7th Floor South 4 1 25"
Echo Chime 7th
Floor North 0 1 5"
Piano 1 Main
Chamber 0 1 ‑20"
(vacuum)
Console 2nd
Floor East 0 2 ‑20" (vacuum)
TOTALS 141 38 399 461 28414
